Specification

• Model number - Fujinon Teleconverter XF2X TC WR
• Release date - June 16, 2016
• Lens configuration - 9 elements in 5 groups
• Focal length - Twice the main lens
• Maximum aperture ratio - Becomes darker by 2 stops (open aperture)
• Minimum aperture - Becomes darker by 2 stops
• Shooting distance range - Almost the same as the main lens
• Shooting magnification - Twice the main lens
• Weight - Approx. 170g (excluding lens cap)
• External dimensions - Ø58mm × 30.2mm (excluding protrusions)
• Bundled items - Lens cap, Rear lens cap RLCP-001, Lens pouch
• Compatible models - Please see compatible lens list

Specification

• Model NameFUJIFILM X-T30 III
• Lens MountFUJIFILM X mount
• Image Sensor23.5mm x 15.6mm (APS-C) X-Trans CMOS 4 with primary color filter
• Number Of Effective Pixels26.1 millions pixels
• Sensor Cleaning SystemUltra Sonic Vibration
• Image Processing EngineX-Processor 5
• Storage MediaSD Card (-2GB), SDHC Card (-32GB), SDXC Card (-2TB), UHS-I
  *Please see the Fujifilm website (https://fujifilm-x.com/support/compatibility/cameras/) to check memory card compatibility.
• File Format Of Still ImageDCF : Compliant with Design rule for Camera File system (DCF2.0)
  JPEG : Exif Ver.2.32
  HEIF : 4:2:2 10bit
  RAW : 14bit RAW (RAF original format)
  TIFF : 8bit / 16bit RGB (In-camera Raw Conversion Only)
• Number Of Recorded Pixels [L] : 3:2: 6240 x 4160, 16:9: 6240 x 3512, 1:1: 4160 x 4160
  [M] : 3:2: 4416 x 2944, 16:9: 4416 x 2488, 1:1: 2944 x 2944
  [S] : 3:2: 3120 x 2080, 16:9: 3120 x 1760, 1:1: 2080 x 2080
  [instax] : instax mini: 1568 x 2080, instax SQUARE: 2080 x 2080, instax WIDE: 3120 x 1984
• Panorama [L] : vertical: 2160 x 9600, horizontal: 9600 x 1440
  [M] : vertical: 2160 x 6400, horizontal: 6400 x 1440
• DimensionsWidth: 118.4mm / Height: 82.8mm / Depth: 46.8mm (Minimum Depth: 31.9mm)
• WeightIncluding Battery And Memory Card: Approx. 378g / Excluding Battery And Memory Card: Approx. 329g
• Operation EnvironmentOperating Temperature: 0℃~+40℃ / Operating Humidity: 10%~80% (no condensation) / Starting up period: Approx. 0.8sec.
• Accessories IncludedLi-ion battery NP-W126S / Headphone adapter / Shoulder strap / Body cap

Sensitivity

• Still Image Standard Output : AUTO1 / AUTO2 / AUTO3 / ISO160~12800 (1/3 step)
  Extended Output : ISO80 / ISO100 / ISO125 / ISO25600 / ISO51200
• Movie Standard Output : AUTO / ISO160~12800 (1/3 step)
  Extended Output : ISO25600
• Exposure Control TTL 256-zone metering: Multi / Spot / Average / Center Weighted
• Exposure Mode P (Program AE) / A (Aperture Priority AE) / S (Shutter Speed Priority AE) / M (Manual Exposure)

Exposure Compensation

• Still-5.0EV~+5.0EV 1/3EV step
• Movie-2.0EV~+2.0EV 1/3EV step

Shutter Speed

• Shutter TypeFocal Plane Shutter
• Mechanical ShutterP Mode: 30sec. to 1/4000sec. / A Mode: 30sec. to 1/4000sec. / S/M Mode: 15min. to 1/4000sec. / Bulb: up to 60min.
• Electronic ShutterP Mode: 30sec. to 1/32000sec. / A Mode: 30sec. to 1/32000sec. / S/M Mode: 15min. to 1/32000sec. / Bulb: 1sec. Fixed
• Electronic Front Curtain ShutterP Mode: 30sec. to 1/4000sec. / A Mode: 30sec. to 1/4000sec. / S/M Mode: 15min. to 1/4000sec. / Bulb: up to 60min.
• Mechanical + Electronic ShutterP Mode: 30sec. to 1/32000sec. / A Mode: 30sec. to 1/32000sec. / S/M Mode: 15min. to 1/32000sec. / Bulb: up to 60min.
• Notes*Mechanical shutter works until 1/4000sec. *Electronic front curtain shutter works until 1/2000sec. *The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash cannot be used.
• Movie Shutter Speed6.2K: 1/4000sec. to 1/24sec. / 4K/DCI4K: 1/4000sec. to 1/24sec. / FHD: 1/4000sec. to 1/24sec.
  *Cannot choose slower shutter speed than framerate.
• Synchronized Shutter Speed For FlashMechanical Shutter: 1/180sec. or slower
• Continuous Shooting — CH Electronic Shutter Approx. 30fps (1.25x Crop)JPEG: 128frames / Compressed RAW: 78frames / Lossless Compressed RAW: 46frames / Uncompressed RAW: 23frames / Compressed RAW + JPEG: 32frames / Lossless Compressed RAW + JPEG: 27frames / Uncompressed RAW + JPEG: 21frames
• Continuous Shooting — Electronic Shutter Approx. 20fps (1.25x Crop)JPEG: 141frames / Compressed RAW: 81frames / Lossless Compressed RAW: 47frames / Uncompressed RAW: 24frames / Compressed RAW + JPEG: 46frames / Lossless Compressed RAW + JPEG: 38frames / Uncompressed RAW + JPEG: 21frames

Focus

• ModeSingle AF, Continuous AF, MF
• TypeIntelligent Hybrid AF (TTL contrast AF / TTL phase detection AF)
• Low-light PerformanceContrast: -4.0EV (XF50mmF1.0 attached) / Phase Detection: -7.0EV (XF50mmF1.0 attached)
• AF Frame SelectionSingle Point AF 13×9 / 25×17 (Changeable size of AF frame)
• Zone AF3×3 / 5×5 / 7×7 / Custom1-3 from 117 areas on 13×9 grid
• Wide/Tracking AFYes (AF-S: Wide / AF-C: Tracking)
• AllYes
• Face/Eye DetectionYes
• Subject DetectionYes (Animal / Bird / Automobile / Motorcycle & Bike / Airplane / Train)

Drive Mode

• AE Bracketing2 frames, 3 frames, 5 frames, 7 frames, 9 frames (*by 1/3EV step, up to ±3EV steps)
• Filmsimulation BracketingAny 3 types of film simulation selectable
• Dynamic Range Bracketing100%, 200%, 400%
• ISO Sensitivity Bracketing±1/3EV, ±2/3EV, ±1EV
• White Balance Bracketing±1, ±2, ±3
• Focus BracketingAUTO, MANUAL
• Multiple ExposureYes (Max. 9 frames) / Additive: Average, Bright, Dark
• HDR ModeAUTO, 200%, 400%, 800%, 800%+
• Advanced FilterToy camera, Miniature, Pop color, High-key, Low-key, Dynamic tone, Soft focus, Partial color (Red / Orange / Yellow / Green / Blue / Purple)
• Self-timer — Still10sec., 2sec.
• Self-timer — Movie10sec., 5sec., 3sec.
• Interval Timer ShootingYes (Setting: Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing, Interval priority mode)
• AUTO Mode SettingAUTO / Portrait / Portrait Enhancer / Landscape / Sport / Night / Night (Tripod) / Fireworks / Sunset / Snow / Beach / Underwater / Party / Flower / Text

Flash

• Built-in FlashManual pop-up flash (Super Intelligent Flash)
• Guide Numberapprox. 7 (ISO200・m) / approx. 5 (ISO100・m)
• Sync. Mode1st Curtain, 2nd Curtain
• Flash ModeTTL (TTL AUTO / STANDARD / SLOW SYNC.), MANUAL, COMMANDER, OFF
• Shoe Mount Flash — Sync. Mode1st Curtain, 2nd Curtain, AUTO FP (HSS)
• Shoe Mount Flash — Flash ModeTTL (TTL AUTO / STANDARD / SLOW SYNC.), MANUAL, MULTI *When EF-X500 is set, OFF
• Hot ShoeYes (Dedicated TTL Flash compatible)

Grain Effect

• RoughnessSTRONG, WEAK, OFF
• SizeLARGE, SMALL
• Color Chrome EffectSTRONG, WEAK, OFF
• Color Chrome BlueSTRONG, WEAK, OFF
• Portrait Enhancer LvSTRONG, MEDIUM, WEAK, OFF
• Film Simulation Mode20 modes: PROVIA/Standard / Velvia/Vivid / ASTIA/Soft / Classic Chrome / REALA ACE / PRO Neg.Hi / PRO Neg.Std / Classic Neg. / Nostalgic Neg. / ETERNA/Cinema / ETERNA BLEACH BYPASS / ACROS / ACROS + Ye Filter / ACROS + R Filter / ACROS + G Filter / Black & White / Black & White + Ye Filter / Black & White + R Filter / Black & White + G Filter / Sepia / Monochromatic Color: Yes
• White BalanceAuto (White Priority / Auto / Ambience Priority) / Custom: Custom1 – 3 / Color Temperature Selection: 2500K~10000K / Preset: Daylight, Shade, Fluorescent Light-1, Fluorescent Light-2, Fluorescent Light-3, Incandescent Light, Underwater
• Clarity Setting±5 steps

Touch Screen Mode

• ViewfinderEVF: 0.39 inch OLED Color Viewfinder, Approx. 2.36 million dots / Coverage Of Viewing Area Vs. Capturing Area: Approx. 100% / Eyepoint: Approx. 17.5mm (from the Rear End of the Camera's Eyepiece) / Diopter Adjustment: -4~+2m-1 / Magnification: 0.62x with 50mm Lens (35mm Equivalent) at infinity and Diopter set to -1.0m-1 / Diagonal Angle Of View: approx. 31° (Horizontal angle of view: approx. 26°) / Built-In Eye Sensor
• LCD Monitor3.0 inch Tilt-Type Touch Screen Color LCD Monitor / Aspect Ratio: 3:2 / Dots: Approx. 1.62 million dots
• Shooting ModeAF, Focus Area, OFF, Double Tap Setting (ON/OFF), Touch Function Setting (ON/OFF), Touch Zoom (ON/OFF), EVF Touch Screen Area Setting
• Playback ModeSwipe, Pinch-in / Pinch-out, Double-tap, Drag
• Wireless TransmitterStandard: IEEE802.11b/g/n (standard wireless protocol) / Encryption: WPA2, WPA3 / Access Mode: Infrastructure
• Bluetooth®Standard: Bluetooth Ver. 5.2 (Bluetooth low energy) / Operating Frequency (Center Frequency): 2402〜2480MHz
• TerminalDigital Interface: USB Type-C USB 10Gbps / HDMI Output: HDMI Micro connector (Type D) / Others: ø2.5mm, stereo mini connector (Microphone & Remote Release) / Hot shoe

Movie Recording

• File FormatMOV (HEVC/H.265, Linear PCM (Stereo sound 24bit / 48KHz sampling)) / MPEG-4 AVC/H.264, Linear PCM (Stereo sound 24bit / 48KHz sampling) / MP4 (MPEG-4 AVC/H.264, AAC)
• Movie CompressionLong GOP
• 6.2K (3:2)File Size: 6240 x 4160 / Frame Rate: 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• 4K / DCI4K (17:9)File Size: 4096 x 2160 / Frame Rate: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• High Speed RecordingFull HD(17:9): 240p, 200p, 120p, 100p at 200Mbps / Full HD(16:9): 240p, 200p, 120p, 100p at 200Mbps
  *For recording movies, use a SD memory card with UHS Speed Class 3 or higher.
  *Selectable bitrate will be changed depends on the setting.
  *Recording time can become short depending on the temperature and/or shooting conditions
• Power SupplyNP-W126S Li-ion battery (included)
• Battery Life For Still ImagesEconomy Mode: Approx. 425 frames / Normal Mode: Approx. 315 frames
  *When XF35mmF1.4 R is set
• Actual Battery Life Of Movie Capture6.2K: Approx. 45min. (29.97p) / 4K: Approx. 40min. (59.94p) / Full HD: Approx. 45min. (59.94p), Approx. 50min. (120P)
  *Face detection is set to OFF
• Continuance Battery Life Of Movie Capture6.2K: Approx. 65min. (29.97p) / 4K: Approx. 50min. (59.94p) / Full HD: Approx. 80min. (59.94p)
  *Face detection is set to OFF
  *Approximate number of frames or movie recording time that can be taken with a fully-charged battery based on CIPA Standard.

Dynamic Range Setting

• StillAUTO / 100％ / 200％ / 400％ / ISO Restriction: DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more
• Movie100％ / 200％ / 400％ / ISO Restriction: DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more

Recording & Output Options

Media Rec (SD memory card)

HDMI Output

HDMI Output (High speed REC HDMI ONLY）

HDMI RAW Output

*1 Bit rate will be changed depending on the subject

*2 The resolution from HDMI output is different from selected setting

*3 When the aspect ratio is not 16:9, the image is output in 16:9 with a black band

*4 The frame rate from HDMI output is different from selected setting

Specification

• Model NameFUJIFILM X-E5
• Lens MountFUJIFILM X mount
• Image Sensor23.5mm x 15.7mm (APS-C) X-Trans CMOS 5 HR with primary color filter
• Number Of Effective Pixels40.2 millions pixels
• Sensor Cleaning SystemUltra Sonic Vibration
• Image Processing EngineX-Processor 5
• Storage MediaSD Card (-2GB) / SDHC Card (-32GB) / SDXC Card (-2TB) / UHS-I / UHS-II / Video Speed Class V90
  *Please see the Fujifilm website to check memory card compatibility.
• File Format Of Still ImageDCF : Compliant with Design rule for Camera File system (DCF2.0)
  JPEG : Exif Ver.2.32
  HEIF : 4:2:2 10bit
  RAW : 14bit RAW (RAF original format)
  TIFF : 8bit / 16bit RGB (In-camera Raw Conversion Only)
  *Exif 2.32 is a digital camera file format that contains a variety of shooting information for optimal printing
• Number Of Recorded Pixels [L] 4:3: 6864 x 5152, 3:2: 7728 x 5152, 16:9: 7728 x 4344, 5:4: 6432 x 5152, 1:1: 5152 x 5152
  [M] 4:3: 4864 x 3648, 3:2: 5472 x 3648, 16:9: 5472 x 3080, 5:4: 4560 x 3648, 1:1: 3648 x 3648
  [S] 4:3: 3456 x 2592, 3:2: 3888 x 2592, 16:9: 3888 x 2184, 5:4: 3264 x 2592, 1:1: 2592 x 2592
• Panorama [L] vertical: 2160 x 9600, horizontal: 9600 x 1440
  [M] vertical: 2160 x 6400, horizontal: 6400 x 1440
• Digital Tele-Converter2.0x / 1.4x / OFF
• DimensionsWidth: 124.9mm / Height: 72.9mm / Depth: 39.1mm (Minimum Depth: 33.0mm)
• WeightIncluding Battery And Memory Card: Approx. 445g / Excluding Battery And Memory Card: Approx. 396g
• Operation EnvironmentOperating Temperature: 0℃~+40℃ / Operating Humidity: 10%~80% (no condensation) / Starting up period: Approx. 0.5sec.
• Accessories IncludedLi-ion battery NP-W126S / Headphone adapter / Shoulder strap / Clip attaching tool / Body cap

Sensitivity

• Still Image — Standard OutputAUTO1 / AUTO2 / AUTO3 / ISO125~12800 (1/3 step)
• Still Image — Extended OutputISO64 / ISO80 / ISO100 / ISO25600 / ISO51200
• Movie — Standard OutputAUTO / ISO125~12800 (1/3 step)
• Movie — Extended OutputISO25600
• Exposure ControlTTL 256-zone metering: Multi / Spot / Average / Center Weighted
• Exposure ModeP (Program AE) / A (Aperture Priority AE) / S (Shutter Speed Priority AE) / M (Manual Exposure)
• Image StabilizerMechanism: Image sensor shift mechanism with 5-axis compensation / Compensation Effect: Center 7.0 stops and Periphery 6.0 stops (*based on CIPA2024 standard, *Pitch/Yaw/Roll compensation, *With XF35mmF1.4 R lens mounted) / Digital Image Stabilization: Yes (movie mode only) / IS MODE BOOST: Yes (movie mode only)

Exposure Compensation

• Still-5.0EV~+5.0EV 1/3EV step
• Movie-2.0EV~+2.0EV 1/3EV step

Shutter Speed

• Shutter TypeFocal Plane Shutter
• Mechanical ShutterP Mode: 30sec. to 1/4000sec. / A Mode: 30sec. to 1/4000sec. / S/M Mode: 15min. to 1/4000sec. / Bulb: up to 60min.
• Electronic ShutterP Mode: 30sec. to 1/180000sec. / A Mode: 30sec. to 1/180000sec. / S/M Mode: 15min. to 1/180000sec. / Bulb: 1sec. Fixed
• Electronic Front Curtain ShutterP Mode: 30sec. to 1/4000sec. / A Mode: 30sec. to 1/4000sec. / S/M Mode: 15min. to 1/4000sec. / Bulb: up to 60min.
  *Mechanical shutter works until 1/4000sec.
• E-front + Mechanical ShutterP Mode: 30sec. to 1/4000sec. / A Mode: 30sec. to 1/4000sec. / S/M Mode: 15min. to 1/4000sec. / Bulb: up to 60min.
  *Electronic front curtain shutter works until 1/2000sec.
• E-front + Mechanical + Electronic ShutterP Mode: 30sec. to 1/180000sec. / A Mode: 30sec. to 1/180000sec. / S/M Mode: 15min. to 1/180000sec. / Bulb: up to 60min.
  *Electronic front curtain shutter works until 1/2000sec, Mechanical shutter works until 1/4000sec. *The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash cannot be used.
• Movie Shutter Speed6.2K: 1/4000sec. to 1/24sec. / 4K/DCI4K: 1/4000sec. to 1/24sec. / FHD: 1/4000sec. to 1/24sec.
  *Cannot choose slower shutter speed than framerate for some settings.
• Synchronized Shutter Speed For FlashMechanical Shutter: 1/180sec. or slower
• Continuous Shooting — CH (Electronic Shutter, 1.29x crop) Approx. 20fpsJPEG: 168frames / Compressed RAW: 66frames / Lossless Compressed RAW: 32frames / Uncompressed RAW: 17frames / Compressed RAW + JPEG: 21frames / Lossless Compressed RAW + JPEG: 20frames / Uncompressed RAW + JPEG: 17frames
• Continuous Shooting — CH (Electronic Shutter, 1.29x crop) Approx. 13fpsJPEG: 1000+ frames / Compressed RAW: 94frames / Lossless Compressed RAW: 25frames / Uncompressed RAW: 21frames / Compressed RAW + JPEG: 48frames / Lossless Compressed RAW + JPEG: 31frames / Uncompressed RAW + JPEG: 19frames
• Continuous Shooting — CH (Electronic Shutter, 1.29x crop) Approx. 10fpsJPEG: 1000+ frames / Compressed RAW: 536frames / Lossless Compressed RAW: 43frames / Uncompressed RAW: 23frames / Compressed RAW + JPEG: 61frames / Lossless Compressed RAW + JPEG: 37frames / Uncompressed RAW + JPEG: 21frames
• Continuous Shooting — CH (Electronic Shutter) Approx. 13fpsJPEG: 163frames / Compressed RAW: 46frames / Lossless Compressed RAW: 21frames / Uncompressed RAW: 18frames / Compressed RAW + JPEG: 24frames / Lossless Compressed RAW + JPEG: 20frames / Uncompressed RAW + JPEG: 19frames
• Continuous Shooting — CH (Electronic Shutter) Approx. 8.9fpsJPEG: 1000+ frames / Compressed RAW: 68frames / Lossless Compressed RAW: 28frames / Uncompressed RAW: 21frames / Compressed RAW + JPEG: 36frames / Lossless Compressed RAW + JPEG: 23frames / Uncompressed RAW + JPEG: 21frames
• Continuous Shooting — CH (Mechanical Shutter) Approx. 8.0fpsJPEG: 1000+ frames / Compressed RAW: 79frames / Lossless Compressed RAW: 22frames / Uncompressed RAW: 20frames / Compressed RAW + JPEG: 30frames / Lossless Compressed RAW + JPEG: 21frames / Uncompressed RAW + JPEG: 20frames
• Continuous Shooting — CL (Mechanical Shutter) Approx. 5.0fpsJPEG: 1000+ frames / Compressed RAW: 1000+ frames / Lossless Compressed RAW: 56frames / Uncompressed RAW: 24frames / Compressed RAW + JPEG: 81frames / Lossless Compressed RAW + JPEG: 27frames / Uncompressed RAW + JPEG: 21frames
• Continuous Shooting — CL (Mechanical Shutter) Approx. 4.0fpsJPEG: 1000+ frames / Compressed RAW: 1000+ frames / Lossless Compressed RAW: 1000+ frames / Uncompressed RAW: 29frames / Compressed RAW + JPEG: 1000+ frames / Lossless Compressed RAW + JPEG: 34frames / Uncompressed RAW + JPEG: 26frames
• Continuous Shooting — CL (Mechanical Shutter) Approx. 3.0fpsJPEG: 1000+ frames / Compressed RAW: 1000+ frames / Lossless Compressed RAW: 1000+ frames / Uncompressed RAW: 60frames / Compressed RAW + JPEG: 1000+ frames / Lossless Compressed RAW + JPEG: 1000+ frames / Uncompressed RAW + JPEG: 34frames
• Pre-shot — Electronic Shutter (1.29x crop) Approx. 20fps-20 frames / -135 frames / -155 frames
• Pre-shot — Electronic Shutter (1.29x crop) Approx. 13fps-13 frames / -177 frames / -190 frames
• Pre-shot — Electronic Shutter (1.29x crop) Approx. 10fps-10 frames / -240 frames / -250 frames
• Pre-shot — Electronic Shutter Approx. 13fps-13 frames / -77 frames / -90 frames
• Pre-shot — Electronic Shutter Approx. 8fps-8 frames / -102 frames / -110 frames
  *No. of recordable frames are calculated based on a cold start. *Recordable frames depends on recording media. *Speed of continuous shooting depends on shooting environment and shooting frames.

Focus

• ModeSingle AF, Continuous AF, MF
• TypeIntelligent Hybrid AF (TTL contrast AF / TTL phase detection AF)
• Low-light PerformanceContrast: -4.0EV (XF50mmF1.0 attached) / Phase Detection: -7.0EV (XF50mmF1.0 attached)
• AF Frame SelectionSingle Point AF: 13×9 / 25×17 (Changeable size of AF frame)
• Zone AF3×3 / 5×5 / 7×7 / Custom1-3 from 117 areas on 13×9 grid
• Wide/Tracking AFYes (AF-S: Wide / AF-C: Tracking)
• AllYes
• Face/Eye DetectionYes
• Subject DetectionYes (Animal / Bird / Automobile / Motorcycle & Bike / Airplane / Train)

Drive Mode

• AE Bracketing2 frames, 3 frames, 5 frames, 7 frames, 9 frames (*by 1/3EV step, up to ±3EV steps)
• Film Simulation BracketingAny 3 types of film simulation selectable
• Dynamic Range Bracketing100% / 200% / 400%
• ISO Sensitivity Bracketing±1/3EV, ±2/3EV, ±1EV
• White Balance Bracketing±1, ±2, ±3
• Focus BracketingAUTO, MANUAL
• Multiple ExposureYes (Max. 9 frames) / Additive: Average, Bright, Dark
• HDR ModeAUTO, 2, 4, 8, 800%+
• Advanced FilterToy camera, Miniature, Pop color, High-key, Low-key, Dynamic tone, Soft focus, Partial color (Red / Orange / Yellow / Green / Blue / Purple)
• Self-timer — Still10sec., 2sec.
• Self-timer — Movie10sec., 5sec., 3sec.
• Interval Timer ShootingYes (Settings: Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing, Interval priority mode)

Flash

• EF-X8 Guide Numberapprox. 11 (ISO200・m) / approx. 8 (ISO100・m)
• Sync. Mode1st Curtain, 2nd Curtain
• Flash ModeTTL (TTL AUTO / STANDARD / SLOW SYNC.), MANUAL, COMMANDER, OFF
• Shoe Mount Flash — Sync. Mode1st Curtain, 2nd Curtain, AUTO FP (HSS)
• Shoe Mount Flash — Flash ModeTTL (TTL AUTO / STANDARD / SLOW SYNC.), MANUAL, MULTI *When EF-X500 is set, OFF
• Hot ShoeYes (Dedicated TTL Flash compatible)

Grain Effect

• RoughnessSTRONG, WEAK, OFF
• SizeLARGE, SMALL
• Color Chrome EffectSTRONG, WEAK, OFF
• Color Chrome BlueSTRONG, WEAK, OFF
• Smooth Skin EffectSTRONG, WEAK, OFF
• Film Simulation Mode20 modes: PROVIA/Standard / Velvia/Vivid / ASTIA/Soft / Classic Chrome / REALA ACE / PRO Neg.Hi / PRO Neg.Std / Classic Neg. / Nostalgic Neg. / ETERNA/Cinema / ETERNA BLEACH BYPASS / ACROS / ACROS + Ye Filter / ACROS + R Filter / ACROS + G Filter / Black & White / Black & White + Ye Filter / Black & White + R Filter / Black & White + G Filter / Sepia / Monochromatic Color: Yes
• White BalanceAuto (White Priority / Auto / Ambience Priority) / Custom: Custom1 – 3 / Color Temperature Selection: 2500K~10000K / Preset: Daylight, Shade, Fluorescent Light-1, Fluorescent Light-2, Fluorescent Light-3, Incandescent Light, Underwater
• Clarity Setting±5 steps

Touch Screen Mode

• ViewfinderEVF: 0.39 inch OLED Color Viewfinder, Approx. 2.36 million dots / Coverage Of Viewing Area Vs. Capturing Area: Approx. 100% / Eyepoint: Approx. 17.5mm (from the Rear End of the Camera's Eyepiece) / Diopter Adjustment: -4~+2m⁻¹ / Magnification: 0.62x with 50mm Lens (35mm Equivalent) at infinity and Diopter set to -1.0m⁻¹ / Diagonal Angle Of View: approx. 31° (Horizontal angle of view: approx. 26°) / Built-In Eye Sensor: Yes
• LCD Monitor3.0 inch Tilt-Type Touch Screen Color LCD Monitor / Aspect Ratio: 3:2 / Dots: Approx. 1.04 million dots
• Shooting ModeShooting AF, Focus Area, OFF, Double Tap Setting (ON/OFF), Touch Function Setting (ON/OFF), Touch Zoom (ON/OFF), EVF Touch Screen Area Setting
• Playback ModeSwipe, Pinch-in / Pinch-out, Double-tap, Drag
• Wireless TransmitterStandard: IEEE802.11a/b/g/n/ac / Encryption: WPA2, WPA3 / Access Mode: Infrastructure
• Bluetooth®Standard: Bluetooth Ver. 4.2 / Operating Frequency: 2402MHz
• TerminalDigital Interface: USB Type-C USB 10Gbps / HDMI Output: HDMI Micro connector (Type D) / Others: ø3.5mm stereo mini connector (Microphone & Remote Release) / Hot shoe

Movie Recording

• File FormatMOV (HEVC/H.265, Linear PCM (Stereo sound 24bit / 48KHz sampling)) / MOV (MPEG-4 AVC/H.264, Linear PCM (Stereo sound 24bit / 48KHz sampling)) / MP4 (MPEG-4 AVC/H.264, AAC)
• Movie CompressionLong GOP
• 6.2K (16:9)File Size: 6240 x 3510 / Frame Rate: 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• DCI4K HQ (17:9)File Size: 4096 x 2160 / Frame Rate: 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• 4K HQ (16:9)File Size: 3840 x 2160 / Frame Rate: 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• DCI4K (17:9)File Size: 4096 x 2160 / Frame Rate: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• 4K (16:9)File Size: 3840 x 2160 / Frame Rate: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• Full HD (17:9)File Size: 2048 x 1080 / Frame Rate: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• Full HD (16:9)File Size: 1920 x 1080 / Frame Rate: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p / Bitrate: 200Mbps, 100Mbps, 50Mbps, 25Mbps, 8Mbps
• Full HD (17:9) High Speed Rec.File Size: 2048 x 1080 / 240p, 200p, 120p, 100p / Bitrate: 200Mbps
• Full HD (16:9) High Speed Rec.File Size: 1920 x 1080 / 240p, 200p, 120p, 100p / Bitrate: 200Mbps
  *For recording movies, use a SD memory card with UHS Speed Class 3 or higher.
  *Selectable bitrate will be changed depends on the setting.
  *Recording time can become short depending on the temperature and/or shooting conditions
• Power SupplyNP-W126S Li-ion battery (included)
• Battery Life For Still ImagesEconomy Mode: Approx. 400 frames / Normal Mode: Approx. 310 frames
  *When XF35mmF1.4 R is set
• Actual Battery Life Of Movie Capture6.2K: Approx. 45min. (29.97p) / 4K: Approx. 45min. (59.94p) / Full HD: Approx. 45min. (59.94p), Approx. 50min. (120P)
  *Face detection OFF
• Continuance Battery Life Of Movie Capture6.2K: Approx. 70min. (29.97p) / 4K: Approx. 70min. (59.94p) / Full HD: Approx. 80min. (59.94p)

Dynamic Range Setting

• StillAUTO / 100% / 200% / 400% / ISO Restriction: DR100%: No limit, DR200%: ISO250 or more, DR400%: ISO500 or more
• Movie100% / 200% / 400% / ISO Restriction: DR100%: No limit, DR200%: ISO250 or more, DR400%: ISO500 or more

Recording & Output Options

Media Rec (SD memory card)

*1 For recording movies, use a SD memory card with UHS Speed Class 3 or higher
*2 *3 *4 Selectable bitrate will be changed depends on the setting

HDMI Output

HDMI Output (High speed REC HDMI ONLY)

HDMI RAW Output

*1 Bit rate will be changed depend on the subject
*2 The resolution from HDMI output is different from selected setting
*3 When the aspect ratio is not 16:9, the image is output in 16:9 with a black band
*4 The frame rate from HDMI output is different from selected setting
